Components and Specifications
2.6 Literature
The following documentation is supplied with each EZ-SCREEN receiver. Additional
copies are available at no charge.
Description Model Number
Panel-mount keyed reset switch MGA-KSO-1
Replacement key for switch MGA-KSO-1 MGA-K-1
Access cover with label – emitter EZA-ADE-1
Access cover with label – receiver EZA-ADR-1
Access cover with inverted label – emitter EZA-ADE-2
Access cover with inverted label – receiver EZA-ADR-2
Access cover security plate (includes 2 screws, wrench) EZA-TP-1
Wrench, security EZA-HK-1
14 mm test piece (for 14 mm resolution systems) STP-13
30 mm test piece (for 14 mm resolution systems with 2-beam Reduced
Resolution and for 30 mm resolution systems)
STP-14
60 mm test piece (for 30 mm resolution systems with 2-beam Reduced
Resolution)
STP-15
Terminator plug for cascaded receiver EZA-RTP-1
Dust cap for cascaded emitter p/n 64790
Standard bracket kit with hardware (includes 2 end
brackets and hardware to mount to MSA Series
stands; see Figure 2-1)
Black EZA-MBK-11
Stainless Steel EZA-MBK-11N
Center bracket kit (includes 1 bracket and hardware to mount to MSA
Series stands), and retrofit for SICK and Leuze Swivel (see Figure 2-1)
EZA-MBK-12
SSM Mirror bracket kit (includes 2 replacement brackets for one mirror) SMA-MBK-1
2.5 Replacement Parts
Description Part #
EZ-SCREEN System Instruction Manual 112852
Checkout Procedure Card (Daily) – Stand-Alone Systems 113361
Checkout Procedure Card (Daily) – Cascaded Systems 118173
Checkout Procedure Card (Semi-Annual) 113362
Diagnostic Display Label 114189
