2.2 Standard Emitter and Receiver Models (Non-Cascadeable) – 30 mm Resolution
Order one 8-pin cable for each 8-pin emitter or receiver, or one 5-pin cable for each 5-pin emitter; see Table
2.3. For cascadeable emitter and receiver models, see Sections 7.2 and 7.3.
Defined
Area Height
Standard 30 mm Resolution Models †
0.1 m to 18 m (4" to 60') range
Emitter (8-pin) † Receiver
Emitter/Receiver
Pair †
Number
of Beams
Response
Time (Tr)
150 mm (5.9") SLSE30-150Q8 SLSR30-150Q8 SLSP30-150Q88 10 9 ms
300 mm (11.8") SLSE30-300Q8 SLSR30-300Q8 SLSP30-300Q88 20 11 ms
450 mm (17.7") SLSE30-450Q8 SLSR30-450Q8 SLSP30-450Q88 30 13 ms
600 mm (23.6") SLSE30-600Q8 SLSR30-600Q8 SLSP30-600Q88 40 15 ms
750 mm (29.5") SLSE30-750Q8 SLSR30-750Q8 SLSP30-750Q88 50 17 ms
900 mm (35.4") SLSE30-900Q8 SLSR30-900Q8 SLSP30-900Q88 60 19 ms
1050 mm (41.3") SLSE30-1050Q8 SLSR30-1050Q8 SLSP30-1050Q88 70 21 ms
1200 mm (47.2") SLSE30-1200Q8 SLSR30-1200Q8 SLSP30-1200Q88 80 23 ms
1350 mm (53.1") SLSE30-1350Q8 SLSR30-1350Q8 SLSP30-1350Q88 90 25 ms
1500 mm (59") SLSE30-1500Q8 SLSR30-1500Q8 SLSP30-1500Q88 100 27 ms
1650 mm (65") SLSE30-1650Q8 SLSR30-1650Q8 SLSP30-1650Q88 110 30 ms
1800 mm (70.9") SLSE30-1800Q8 SLSR30-1800Q8 SLSP30-1800Q88 120 32 ms
1950 mm (76.8") SLSE30-1950Q8 SLSR30-1950Q8 SLSP30-1950Q88 130 34 ms
2100 mm (82.7") SLSE30-2100Q8 SLSR30-2100Q8 SLSP30-2100Q88 140 36 ms
2250 mm (88.6") SLSE30-2250Q8 SLSR30-2250Q8 SLSP30-2250Q88 150 38 ms
2400 mm (94.5") SLSE30-2400Q8 SLSR30-2400Q8 SLSP30-2400Q88 160 40 ms
† Only standard 8-pin QD models are listed; 8-pin emitters/receivers feature “swapable” hookup; see Sections 3.3 and 3.7.
For other models:
5-pin emitters with Test input: Replace suffix “Q8” with “Q5”, (e.g., SLSE30-150Q5), and
for the pair replace “Q88” with “Q85” (e.g., SLSP30-150Q85).
Pigtail QD (8-pin models only): Replace the “Q” in the model number with “P” (e.g., SLSE30-150P8).
ESD-safe models: Add “N” to the model number, prior to the QD option designation (e.g., SLSE30-150NQ8). ESD-safe models are not
available with the pigtail QD option.
Op tional housing finishes: Prior to the QD designation in the model number,
add “A” for a clear (brushed) anodized aluminum finish, black endcaps (e.g., SLSE30-150AQ8),
add “S” for a nickel-plated (“silver”) finish, black endcaps (e.g., SLSE30-150SQ8),
add “B” for a black painted finish, black endcaps (e.g., SLSE30-150BQ8),
add “W” for a white painted finish, black endcaps (e.g., SLSE30-150WQ8), or
add “SO” for a “safety orange” painted finish, black endcaps (e.g., SLSE30-150SOQ8).
