Rockwell Automation Publication DRIVES-IN001M-EN-P - March 2014 97
Motor Cable Length Restrictions Tables Appendix A
Table 28 - PowerFlex 70 (standard/enhanced) and 700 (standard/vector) Drives, 600V Shielded/Unshielded Cable – Meters (Feet)
Drive
Frame Rating No Solution Reactor Only 1321-RWR RWR
(see page 129 )
Available Options
70 700
Hp kHz 1488V 1850V 1488V 1850V 1488V 1850V Cat. No.
TF
A1
TF
B
2
RW
R2
RW
C
A
0
1
2 42.7 (140) 121.9 (400) 121.9 (400) 121.9 (400) 121.9 (400) 121.9 (400) ● ● ●
4 30.5 (100) 121.9 (400) 30.5 (100) 121.9 (400) 121.9 (400) 121.9 (400) ● ●
2
2 42.7 (140) 152.4 (500) 152.4 (500) 152.4 (500) 152.4 (500) 152.4 (500) ● ● ●
4 30.5 (100) 137.2 (450) 30.5 (100) 152.4 (500) 152.4 (500) 152.4 (500) ● ●
B
3
2 42.7 (140) 152.4 (500) 152.4 (500) 182.9 (600) 182.9 (600) 182.9 (600) ● ● ●
4 30.5 (100) 137.2 (450) 30.5 (100) 152.4 (500) 182.9 (600) 182.9 (600) ● ●
5
2 42.7 (140) 152.4 (500) 152.4 (500) 243.8 (800) 243.8 (800) 243.8 (800) 1321-RWR8-EP ● ● ●
4 30.5 (100) 137.2 (450) 30.5 (100) 152.4 (500) 243.8 (800) 243.8 (800) 1321-RWR8-EP ● ●
C
7.5
2 42.7 (140) 152.4 (500) 152.4 (500) 304.8 (1000) 304.8 (1000) 304.8 (1000) 1321-RWR12-EP ●
4 30.5 (100) 137.2 (450) 30.5 (100) 152.4 (500) 304.8 (1000) 304.8 (1000) 1321-RWR12-EP ●
1
10
2 42.7 (140) 182.9 (600) 152.4 (500) 365.8 (1200) 365.8 (1200) 365.8 (1200) 1321-RWR12-EP ●
4 30.5 (100) 137.2 (450) 30.5 (100) 152.4 (500) 304.8 (1000) 365.8 (1200) 1321-RWR12-EP ●
D
15
2 42.7 (140) 182.9 (600) 152.4 (500) 365.8 (1200) 365.8 (1200) 365.8 (1200) 1321-RWR18-EP
4 30.5 (100) 137.2 (450) 30.5 (100) 152.4 (500) 304.8 (1000) 365.8 (1200) 1321-RWR18-EP
2
20
2 42.7 (140) 182.9 (600) 152.4 (500) 365.8 (1200) 365.8 (1200) 365.8 (1200) 1321-RWR25-EP ●
4 30.5 (100) 137.2 (450) 30.5 (100) 152.4 (500) 304.8 (1000) 365.8 (1200) 1321-RWR25-EP
25
2 42.7 (140) 182.9 (600) 152.4 (500) 365.8 (1200) 365.8 (1200) 365.8 (1200) 1321-RWR35-EP ●
4 30.5 (100) 137.2 (450) 30.5 (100) 152.4 (500) 304.8 (1000) 365.8 (1200) 1321-RWR35-EP
3
30
2 42.7 (140) 182.9 (600) 152.4 (500) 365.8 (1200) 365.8 (1200) 365.8 (1200) 1321-RWR35-EP ●
4 30.5 (100) 137.2 (450) 36.6 (120) 152.4 (500) 304.8 (1000) 365.8 (1200) 1321-RWR35-EP
E
40
2 42.7 (140) 182.9 (600) 152.4 (500) 365.8 (1200) 365.8 (1200) 365.8 (1200) 1321-RWR45-EP ●
4 30.5 (100) 137.2 (450) 36.6 (120) 152.4 (500) 304.8 (1000) 365.8 (1200) 1321-RWR45-EP
50
2 42.7 (140) 182.9 (600) 152.4 (500) 365.8 (1200) 365.8 (1200) 365.8 (1200) 1321-RWR55-EP ●
4 36.6 (120) 137.2 (450) 45.7 (150) 152.4 (500) 304.8 (1000) 365.8 (1200) 1321-RWR55-EP
4 60
2 42.7 (140) 182.9 (600) 152.4 (500) 365.8 (1200) 365.8 (1200) 365.8 (1200) 1321-RWR80-EP ●
4 36.6 (120) 137.2 (450) 45.7 (150) 152.4 (500) 274.3 (900) 365.8 (1200) 1321-RWR80-EP
5
75
2 42.7 (140) 182.9 (600) 152.4 (500) 365.8 (1200) 365.8 (1200) 365.8 (1200) 1321-RWR80-EP ●
4 36.6 (120) 137.2 (450) 45.7 (150) 152.4 (500) 274.3 (900) 365.8 (1200) 1321-RWR80-EP
100
2 42.7 (140) 182.9 (600) 152.4 (500) 304.8 (1000) 365.8 (1200) 365.8 (1200) 1321-RWR100-EP ●
4 42.7 (140) 137.2 (450) 45.7 (150) 152.4 (500) 274.3 (900) 365.8 (1200) 1321-RWR100-EP
6
125
2 42.7 (140) 182.9 (600) 121.9 (400) 304.8 (1000) 365.8 (1200) 365.8 (1200) 1321-RWR130-EP ●
4 42.7 (140) 137.2 (450) 45.7 (150) 152.4 (500) 228.6 (750) 365.8 (1200) 1321-RWR130-EP
150
2 42.7 (140) 182.9 (600) 121.9 (400) 304.8 (1000) 365.8 (1200) 365.8 (1200) 1321-RWR160-EP ●
4 42.7 (140) 137.2 (450) 45.7 (150) 152.4 (500) 198.1 (650) 365.8 (1200) 1321-RWR160-EP
