Rockwell Automation Publication DRIVES-IN001M-EN-P - March 2014 83
Motor Cable Length Restrictions Tables Appendix A
Motor Cable Length Restrictions Tables Cross Reference
Use this table to find the drive and voltage rating that you are looking for.
Drive Voltage Table Page Drive Voltage Table Page
PowerFlex 4 400 14 84 PowerFlex 700S 400 42 104
480 15 84 480 43 105
PowerFlex 4M 400 16 85 600 44 107
480 17 85 690 45 108
PowerFlex 40 400 18 86 PowerFlex 753 and 755 (wall mount) 400 46 109
480 19 86 480 47 111
600 20 87 600 48 114
PowerFlex 400 400 21 88 690 49 117
480 22 89 PowerFlex 755 (floor mount) 400 50 118
PowerFlex 525 400 23 90 480 51 120
480 24 91 600 52 121
600 25 92 690 53 123
PowerFlex 70 (standard/enhanced)
PowerFlex 700 (standard/vector)
400 26 93 1336 PLUS II
1336 IMPACT
380…480 54 124
480 27 95 600 55 126
600 28 97 1305 (no external devices) 480 56 127
PowerFlex 700 (standard/vector) 690 29 98 1305 (external devices at motor) 480 57 127
PowerFlex 700H 400 30 98 160 480 58 127
480 31 99 160 (cable charging current) 240 and 480 59 128
600 32 100
690 33 100
PowerFlex 700L with
PowerFlex 700VC Control
400 34 101
480 35 101
600 36 101
690 37 102
PowerFlex 700L with
PowerFlex 700S Control
400 38 102
480 39 102
600 40 103
690 41 103
