Appendix A Motor Cable Length Restrictions Tables
PowerFlex 40 Drives
This section lists motor cable length restrictions, reactors, and available options
for PowerFlex 40 Drives.
Table 18 - PowerFlex 40 Drives, 400V Shielded/Unshielded Cable – Meters (Feet)
Table 19 - PowerFlex 40 Drives, 480V Shielded/Unshielded Cable – Meters (Feet)
Rating
No Solution
Reactor Only
Reactor and Damping Resistor
or 1321-RWR
Reactor/RWR
Resistor
Available Options
kW
kHz
1000V 1200V 1488V 1600V 1000V 1200V 1488V 1600V 1000V 1200V 1488V 1600V Cat. No.
Ohms
Watts
TF
A1
TFB
2
RW
R
2
RW
C
0.4
2/4
7.6
(25)
53.3
(175)
53.3
(175)
53.3
(175)
91.4
(300)
121.9
(400)
121.9
(400)
121.9
(400)
121.9
(400)
121.9
(400)
121.9
(400)
121.9
(400)
●
●
●
0.75
2/4
7.6
(25)
83.8
(275)
83.8
(275)
83.8
(275)
91.4
(300)
152.4
(500)
152.4
(500)
152.4
(500)
152.4
(500)
152.4
(500)
152.4
(500)
152.4
(500)
●
●
●
1.5
2/4
7.6
(25)
83.8
(275)
83.8
(275)
83.8
(275)
91.4
(300)
152.4
(500)
152.4
(500)
152.4
(500)
152.4
(500)
152.4
(500)
152.4
(500)
152.4
(500)
●
●
●
●
2.2
2/4
7.6
(25)
137.2
(450)
182.9
(600)
182.9
(600)
91.4
(300)
182.9
(600)
182.9
(600)
182.9
(600)
182.9
(600)
182.9
(600)
182.9
(600)
182.9
(600)
1321-RWR8-DP
●
●
●
●
4
2/4
7.6
(25)
137.2
(450)
243.8
(800)
243.8
(800)
91.4
(300)
243.8
(800)
243.8
(800)
243.8
(800)
243.8
(800)
243.8
(800)
243.8
(800)
243.8
(800)
1321-RWR12-DP
●
●
●
5.5
2/4
7.6
(25)
137.2
(450)
304.8
(1000)
304.8
(1000)
91.4
(300)
304.8
(1000)
304.8
(1000)
304.8
(1000)
304.8
(1000)
304.8
(1000)
304.8
(1000)
304.8
(1000)
1321-RWR12-DP
●
●
7.5
2/4
7.6
(25)
137.2
(450)
365.8
(1200)
365.8
(1200)
91.4
(300)
365.8
(1200)
365.8
(1200)
365.8
(1200)
365.8
(1200)
365.8
(1200)
365.8
(1200)
365.8
(1200)
1321-RWR18-DP
●
●
11
2/4
7.6
(25)
137.2
(450)
365.8
(1200)
365.8
(1200)
91.4
(300)
365.8
(1200)
365.8
(1200)
365.8
(1200)
365.8
(1200)
365.8
(1200)
365.8
(1200)
365.8
(1200)
1321-RWR25-DP
●
Rating
No Solution
Reactor Only
Reactor and Damping Resistor
or 1321-RWR
Reactor/RWR
Resistor
Available Options
Hp
kHz
1000V 1200V 1488V 1600V 1000V 1200V 1488V 1600V 1000V 1200V 1488V 1600V Cat. No.
Ohms
Watts
TF
A1
TF
B2
RW
R2
RW
C
0.5
2/4
7.6
(25)
12.2
(40)
53.3
(175)
53.3
(175)
7.6
(25)
91.4
(300)
121.9
(400)
121.9
(400)
121.9
(400)
121.9
(400)
121.9
(400)
121.9
(400)
●
●
●
1
2/4
7.6
(25)
12.2
(40)
83.8
(275)
83.8
(275)
7.6
(25)
91.4
(300)
152.4
(500)
152.4
(500)
152.4
(500)
152.4
(500)
152.4
(500)
152.4
(500)
●
●
●
2
2/4
7.6
(25)
12.2
(40)
83.8
(275)
83.8
(275)
7.6
(25)
91.4
(300)
182.9
(600)
182.9
(600)
182.9
(600)
182.9
(600)
182.9
(600)
182.9
(600)
●
●
●
●
3
2/4
7.6
(25)
12.2
(40)
129.5
(425)
129.5
(425)
7.6
(25)
91.4
(300)
182.9
(600)
182.9
(600)
182.9
(600)
182.9
(600)
182.9
(600)
182.9
(600)
1321-RWR8-DP
●
●
●
●
5
2/4
7.6
(25)
12.2
(40)
137.2
(450)
182.9
(600)
7.6
(25)
91.4
(300)
243.8
(800)
243.8
(800)
243.8
(800)
243.8
(800)
243.8
(800)
243.8
(800)
1321-RWR12-DP
●
●
●
7.5
2/4
7.6
(25)
12.2
(40)
137.2
(450)
182.9
(600)
7.6
(25)
91.4
(300)
304.8
(1000)
304.8
(1000)
182.9
(600)
304.8
(1000)
304.8
(1000)
304.8
(1000)
1321-RWR12-DP
●
●
10
2/4
7.6
(25)
12.2
(40)
137.2
(450)
182.9
(600)
7.6
(25)
91.4
(300)
365.8
(1200)
365.8
(1200)
182.9
(600)
365.8
(1200)
365.8
(1200)
365.8
(1200)
1321-RWR18-DP
●
●
15
2/4
7.6
(25)
12.2
(40)
137.2
(450)
182.9
(600)
7.6
(25)
91.4
(300)
365.8
(1200)
365.8
(1200)
182.9
(600)
365.8
(1200)
365.8
(1200)
365.8
(1200)
1321-RWR25-DP
●
