Rockwell Automation Publication DRIVES-IN001M-EN-P - March 2014 31
Power Distribution Chapter 2
Table 5 - AC Line Impedance Recommendations for Bulletin 1305 Drives
Table 6 - AC Line Impedance Recommendations for PowerFlex 4 Drives
Bulletin
Number Drive Catalog
Number
(1)
(1) Shaded rows identify drive ratings without built-in inductors.
Volts kW (Hp) Max Supply
kVA
(2)
(2) Maximum suggested KVA supply without consideration for additional inductance.
3% Line Reactor
Open Style 1321- Reactor Inductance
(mH) Reactor Current
Rating (amps)
1305 -AA02A 240 0.37(0.5) 15 3R4-A 3 4
-AA03A 240 0.55 (0.75) 20 3R4-A 4 4
-AA04A 240 0.75 (1) 30 3R8-A 1.5 8
-AA08A 240 1.5 (2) 50 3R8-A 1.5 8
-AA12A 240 2.2 (3) 75 3R18-A 0.8 18
-BA01A 480 0.37 (0.5) 15 3R2-B 20 2
-BA02A 480 0.55 (0.75) 20 3R2-B 20 2
-BA03A 480 0.75 (1) 30 3R4-B 6.5 4
-BA04A 480 1.5 (2) 50 3R4-B 6.5 4
-BA06A 480 2.2 (3) 75 3R8-B 3 8
-BA09A 480 3.7 (5) 100 3R18-B 1.5 18
Drive Drive Catalog
Number
(1)
(1) Shaded rows identify drive ratings without built-in inductors.
Volts kW (Hp) Max Supply
kVA 3% Line Reactor
Open Style 1321- Reactor Inductance
(mH) Reactor Current
Rating (amps)
PowerFlex
4
22AB1P5 240 0.2 (0.25) 15 3R2-A 12 2
22AB2P3 240 0.4 (0.5) 25 3R4-B 6.5 4
22AB4P5 240 0.75 (1.0) 50 3R8-B 3 8
22AB8P0 240 1.5 (2.0) 100 3R8-A 1.5 8
22AB012 240 2.2 (3.0) 125 3R12-A 1.25 12
22AB017 240 3.7 (5.0) 150 3R18-A 0.8 18
22AD1P4 480 0.4 (0.5) 15 3R2-B 20 2
22AD2P3 480 0.75 (1.0) 30 3R4-C 9 4
22AD4P0 480 1.5 (2.0) 50 3R4-B 6.5 4
22AD6P0 480 2.2 (3.0) 75 3R8-C 5 8
22AD8P7 480 3.7 (5.0) 100 3R8-B 3 8
