Rockwell Automation Publication DRIVES-IN001M-EN-P - March 2014 41
Power Distribution Chapter 2
PowerFlex
753/755
For
PowerFlex
753,
replace 20G
with 20F.
20G_F500 690 500(670) 3000 3R500-B 0.05 500
20G_F590 690 560 (750) 3500 3R600-B 0.04 600
20G_F650 690 630 (845) 4500 3R750-B 0.029 750
20G_F710 690 710 (952) 4500 3R750-B 0.029 750
20G_F765 690 750 (1006) 5000 3R850-B 0.027 850
20G_F795 690 800 (1073) 5000 3R850-B 0.027 850
20G_F960 690 900 (1207) 5000 3R1000-B 0.022 1000
20G_F1K0 690 1000(1341) 5000 3R1000-B 0.022 1000
20G_F1K4 690 1400 (1877) 5000 2 x 3R750-B 0.015 1500
(1) Maximum suggested KVA supply without consideration for additional inductance.
Table 13 - AC Line Impedance Recommendations for Bulletin 1336 Drives
Drive Drive Catalog
Number
(1)
Volts kW (Hp) Max Supply
kVA
(2)(3)
3% Line Reactor
Open Style, 1321- Reactor Inductance
(mH) Reactor Current
Rating (amps)
(4)
1336 PLUS,
PLUS II
IMPACT
FORCE AQF05 240 0.37 (0.5) 25 3R4-A 3.0 4
AQF07 240 0.56 (0.75) 25 3R4-A 3.0 4
AQF10 240 0.75 (1) 50 3R8-A 1.5 8
AQF15 240 1.2 (1.5) 75 3R8-A 1.5 8
AQF20 240 1.5 (2) 100 3R12-A 1.25 12
AQF30 240 2.2 (3) 200 3R12-A 1.25 12
AQF50 240 3.7 (5) 275 3R25-A 0.5 25
AQF75 240 5.5 (7.5) 300 3R25-A 0.5 25
A7 240 5.5 (7.5) 300 3R25-A 0.5 25
A10 240 7.5 (10) 350 3R35-A 0.4 35
A15 240 11 (15) 600 3R45-A 0.3 45
A20 240 15 (20) 800 3R80-A 0.2 80
A25 240 18.5 (25) 800 3R80-A 0.2 80
A30 240 22 (30) 950 3R80-A 0.2 80
A40 240 30 (40) 1000 3R130-A 0.1 130
A50 240 37 (50) 1000 3R160-A 0.075 160
A60 240 45 (60) 1000 3R200-A 0.55 200
A75 240 56 (75) 1000 3RB250-A 0.045 250
A100 240 75 (100) 1000 3RB320-A 0.04 320
A125 240 93 (125) 1000 3RB320-A 0.04 320
BRF05 480 0.37 (0.5) 25 3R2-B 20 2
BRF07 480 0.56 (0.75) 30 3R2-B 20 2
BRF10 480 0.75 (1) 30 3R4-B 6.5 4
BRF15 480 1.2 (1.5) 50 3R4-B 6.5 4
BRF20 480 1.5 (2) 50 3R8-B 3.0 8
BRF30 480 2.2 (3) 75 3R8-B 3.0 8
BRF50 480 3.7 (5) 100 3R12-B 2.5 12
BRF75 480 5.5 (7.5) 200 3R18-B 1.5 18
BRF100 480 7.5 (10) 275 3R25-B 1.2 25
BRF150 480 11 (15) 300 3R25-B 1.2 25
BRF200 480 15 (20) 350 3R25-B 1.2 25
B015 480 11 (15) 350 3R25-B 1.2 25
B020 480 15 (20) 425 3R35-B 0.8 35
continued
Table 12 - AC Line Impedance Recommendations for PowerFlex 753/755 Drives (Continued)
Drive Drive Catalog
Number Volts kW (Hp) Max Supply
KVA
(1)
3% Line Reactor
Open Style 1321- Reactor Inductance
(mH) Reactor Current
Rating (amps)
