38 Rockwell Automation Publication DRIVES-IN001M-EN-P - March 2014
Chapter 2 Power Distribution
Table 12 - AC Line Impedance Recommendations for PowerFlex 753/755 Drives
Drive Drive Catalog
Number Volts kW (Hp) Max Supply
KVA
(1)
3% Line Reactor
Open Style 1321- Reactor Inductance
(mH) Reactor Current
Rating (amps)
PowerFlex
753/755
For
PowerFlex
753,
replace 20G
with 20F.
20G_RC2P1 400 0.75 (1) 250 3R2-B 20 2
20G_RC3P5 400 1.5(2) 500 3R4-B 6.5 4
20G_RC5P0 400 2.2 (3) 500 3R4-B 6.5 4
20G_RC8P7 400 4 (5) 500 3R8-B 3 8
20G_RC011 400 5.5 (7.5) 750 3R12-B 2.5 12
20G_RC015 400 7.5 (10) 1000 3R18-B 1.5 18
20G_C2P1 400 0.75 (1) 250 3R2-B 20 2
20G_C3P5 400 1.5(2) 500 3R4-B 6.5 4
20G_C5P0 400 2.2 (3) 500 3R4-B 6.5 4
20G_C8P7 400 4 (5) 500 3R8-B 3 8
20G_C011 400 5.5 (7.5) 750 3R12-B 2.5 12
20G_C015 400 7.5 (10) 1000 3R18-B 1.5 18
20G_C022 400 11 (15) 1000 3R25-B 1.2 25
20G_C030 400 15 (20) 1000 3R35-B 0.8 35
20G_C037 400 18.5(25) 1000 3R45-B 0.7 45
20G_C043 400 22 (30) 1000 3R45-B 0.7 45
20G_C060 400 30 (40) 1000 3R80-B 0.4 80
20G_C072 400 37 (50) 1000 3R80-B 0.4 80
20G_C085 400 45 (60) 1000 3R130-B 0.2 130
20G_C105 400 55 (75) 1000 3R130-B 0.2 130
20G_C125 400 55 (75) 1000 3R130-B 0.2 130
20G_C140 400 75 (100) 1000 3R160-B 0.15 160
20G_C170 400 90 (125) 1500 3R200-B 0.11 200
20G_C205 400 110 (150) 2000 3R200-B 0.11 200
20G_C260 400 132 (175) 2500 3RB320-B 0.075 320
20G_C302 400 160 (214) 2500 3RB320-B 0.075 320
20G_C367 400 200 (268) 3000 3RB400-B 0.06 400
20G_C456 400 250 (335) 3500 3R500-B 0.05 500
20G_C460 400 250 (335) 3500 3R500-B 0.05 500
20G_C567 400 315(422) 4000 3R600-B 0.04 600
20G_C650 400 355 (476) 4500 3R750-B 0.029 750
20G_C750 400 400 (536) 4500 3R750-B 0.029 750
20G_C770 400 400(536) 5000 3R850-B 0.027 850
20G_C1K0 400 500 (670) 5000 3R1000-B 0.022 1000
20G_C1K2 400 560 (750) 5000 2 x 3R750-B 0.015 1500
20G_C1K4 400 630 (175) 5000 2 x 3R750-B 0.015 1500
20G_C1K5 400 850 (1070) 5000 2 x 3R850-B 0.014 1700
20G_C1K6 400 900 (1200) 5000 2 x 3R850-B 0.014 1700
20G_C2K1 400 1250 (1675) 5000 2 x 3R1000-B 0.011 2000
20G_RD2P1 480 0.75 (1) 250 3R2-B 20 2
20G_RD3P4 480 1.5(2) 500 3R4-B 6.5 4
20G_RD5P0 480 2.2 (3) 500 3R4-B 6.5 4
20G_RD8P0 480 4 (5) 500 3R8-B 3 8
20G_RD011 480 5.5 (7.5) 750 3R12-B 2.5 12
20G_RD014 480 7.5 (10) 1000 3R18-B 1.5 18
20G_D2P1 480 0.75 (1) 250 3R2-B 20 2
20G_D3P4 480 1.5 (2) 500 3R4-B 6.5 4
continued
