Page 78 AutoMax ControlNet Module
Publication number DSMBCN-UM001B-EN-P February 2003
Specifications
The MBCN is a standard AutoMax module with the following
specifications:
Parameter Specification
Module Location
AutoMax chassis
Function
AutoMax ControlNet communication module
Dimensions
Height: 29.85 cm (11.75 inches)
Width: 3.18 cm (1.25 inches)
Depth: 18.73 cm (7.375 inches)
Weight: 0.9 kg (2 pounds)
Description
Intel i960 processor
1 Mbyte of local i960 RAM
64 Kbytes of onboard shared memory
512 Kbytes of sectored flash memory, for
storage of program and configuration data
Maximum Backplane
Current Load
+ 5 VDC 350mA
+12 VDC (not used)
-12 VDC (not used)
Environmental
Conditions:
Operational
Temperature
0-55°C (32-140°F)
Storage Temperature
–40 to 85°C (–40 to 185°F)
Relative Humidity
5-95% without condensation
