Rockwell Automation AutoMax ControlNet Communication Interface Module - Manual (Page 37)

AutoMax ControlNet Module Page 37
Publication number DSMBCN-UM001B-EN-P February 2003
General
Status,
hex
Extended
Status,
hex
Explanation
03* n/a Invalid connection number specified by the
Get_Connection_Data service. This is also returned
by the Search_Connection_Data service if the
specified connection is not found.
04 Zero
Based
Word
Offset
Segment Type in path is invalid. The Extended
Status shall be the word offset (0 based) to the word
in the path where the error occurred. The offset
starts at the first word after the path size. This error
shall not be returned if an error occurs when parsing
the Connection Path.
05 Zero
Based
Word
Offset
Destination in path is invalid. The Extended Status
shall be the word offset (0 based) to the word in the
path where the error occurred. The offset starts at
the first word after the path size. This error shall not
be returned if an error occurs when parsing the
Connection Path.
07 n/a Connection has been lost. This is used by the
Get/Set Services when they are made through a
connection.
08 n/a Connection Manager does not support the
requested Service.
09 Index to
Element
Error in Data Segment. Extended Status shall be
index to where the error was encountered in the
Data Segment. The Configuration Revision Number
if present in the Data Segment shall always be index
1. If the error occurs with the Get/Set Services, then
the extended status indicates the attribute number
that failed.
0C Optional Service cannot be performed while Object is in
current state. The 1st word of Extended Status may
optionally contain the object’s current state.
This could occur if you are making changes while in
run mode.
10 Optional Service cannot be performed while Device is in
current state. The 1st word of Extended Status may
optionally contain the device’s current state.
This could be caused by an offline unscheduled
device, or the keeper is in a faulted state.
11 n/a Response data too large. This is used by the get
services to indicate the amount of data requested
was too large to fit into the response buffer.
13 n/a Not enough data was received.
14 Attribute Id Attribute specified in FIND service is not supported
by Connection Manager
