Page 52 AutoMax ControlNet Module
Publication number DSMBCN-UM001B-EN-P February 2003
Code, hex Description
11 Destination memory full, cannot accept
command now
12 Destination did not acknowledge command
13 Network contention, possible duplicate node or
bad cabling
14 Local port is disconnected, or no other node
found
15 Timeout waiting for a reply message
16 Duplicate node detected
17 Node is offline
18 Hardware fault
1D Transaction number mismatch
1E Duplicate transaction number
31 Illegal command or format
32 Host is malfunctioning and will not
communicate
33 Remote node host is missing, disconnected, or
shut down
34 Host could not complete function due to
hardware fault
35 Addressing problem or memory protected
rungs
36 Function disallowed due to command
protection selection
37 A-B Processor is in program mode
38 Compatibility mode file missing or
communication zone problem
39 Remote node cannot buffer command
3A (not used)
3B Remote node problem due to download
3C Cannot execute command due to active IPBs
3D (not used)
3E (not used)
3F There is an error code in the Extended Status
register (register 33 on the module). See
section 0.
Figure 13 Local and Remote Status Table
