AutoMax ControlNet Module Page 35
Publication number DSMBCN-UM001B-EN-P February 2003
Monitoring Module Operation
There are various registers on the MBCN that can be used to monitor the
operating status.
Status of Each Connection
You can use RSNetWorx to view the status of each connection.
Start the Scanlist Configuration for the MBCN and click on the
Connection Status tab. RSNetWorx displays Success for connections
that are operating correctly or gives an explanation for connections that
are not.
The MBCN also contains a status table that shows the status of each
connection, in registers 15362 to 15615.
Each entry consists of two 16-bit registers. The first is the General
Status, the second is the Extended Status. You assign the location of the
entry for a connection in RSNetWorx.
The following table shows possible status values.
General
Status,
hex
Extended
Status,
hex
Explanation
00 Service completed successfully.
01 0100 Connection in Use or Duplicate Forward Open.
01 0103 Transport Class and Trigger combination not
supported
01 0106 Ownership Conflict
01 0107 Connection not found at target application. Could
be a buffer ID mismatch for scheduled produced and
consumed connections.
01 0108 Invalid Connection Type. Indicates a problem with
either the Connection Type or Priority of the
Connection.
01 0109 Invalid Connection Size. Check the sizes of
scheduled produced and consumed connections.
01 0110 Device not configured
01 0111 RPI not supported. May also indicate problem with
the connection time-out multiplier.
01 0113 Connection Manager cannot support any more
connections
01 0114 Either the Vendor Id or the Product Code in the key
segment did not match the device
