AutoMax ControlNet Module Page 65
Publication number DSMBCN-UM001B-EN-P February 2003
Name Location Description
with the network, configured length doesn’t
match the actual length, unconfigured
repeaters, etc.
RxAbort 9357 Frame Received – Aborted
Lonely 9358 The MBCN did not hear anyone else on the
network for 1.75 seconds
DupNode 9359 The MBCN heard a frame whose source
address is the same as the MBCN’s address
NoiseHits 9360 A signal was heard from the network but not
long enough to be valid
Collisions 9361 The MBCN thought it was its turn to transmit,
but another node was already transmitting
ModMacID 9362 Address of the current moderator
NonLowMods 9363 Moderator heard from a address which is not
the lowest on the network
RogueCount 9364 The MBCN’s network parameters don't match
the network’s
UnHeardMod 9365 The MBCN has not heard a moderator frame
for 3 NUTs
Figure 25 Standard ControlNet Diagnostic Counters
Module Specific Counters
The following counters are not part of the ControlNet specification but
are included in the MBCN to provide additional network information.
Name Location Description
RxOverRun 9376 Frames coming in faster than the MBCN can
deal with them
SchLenErr 9377 Invalid Length in scheduled receive frame
FifoSynErr 9378 Synchronization Error - Invalid Rx Frame
FifoLenErr 9379 FIFO Length Error - Invalid Rx Frame
FifoTagErr 9380 FIFO Tag Error - Invalid Rx Frame
MsgsSentOk 9381 High Level Messages Sent OK - high level
means actual messages, not null packets,
network overhead, and so on
MsgsRecdOk 9382 High Level Messages Received OK
CmdRecdOk 9383 High Level Commands Received OK
CmdSentOk 9384 High Level Commands Sent OK
