AutoMax ControlNet Module Page 53
Publication number DSMBCN-UM001B-EN-P February 2003
Extended Status (EXT_STS) Codes for Command 0F
If the value in the upper byte of the GATEWAY_CMD_OK@ "status"
parameter variable is 3F, then there is a value in the upper byte of the
extended status register (register 33 on the module) that supplies further
information.
The following table shows possible values for the extended status error
code.
Code, hex Description
0 (not used)
1 A field has an illegal value
2 Less levels specified in address than minimum
for any address
3 More levels specified than system supports
4 Symbol not found
5 Symbol is of improper format
6 Address doesn't point to something usable
7 File is wrong size
8 Cannot complete request; situation has
changed since the start of the command
9 Data or file is too large
A Transaction size plus word address is too large
B Access denied, improper privilege
C Condition cannot be generated; resource is not
available
D Condition already exists; resource is already
available
E Command cannot be executed
F Histogram overflow
10 No access
11 Illegal data type
12 Invalid parameter or invalid data
13 Address reference exists to deleted area
14 Command execution failure for unknown
reason; possible PLC-3 histogram overflow
15 Data conversion error
