Page 38 AutoMax ControlNet Module
Publication number DSMBCN-UM001B-EN-P February 2003
General
Status,
hex
Extended
Status,
hex
Explanation
15 n/a Too much data was received.
25 0114 Either the Vendor Id or the Product Code in the key
segment did not match the device. Used if the Key
Segment was contained in the path.
25 0115 Product Type in the key segment did not match the
device. Used if the Key Segment was contained in
the path.
25 0116 Major or Minor Revision information in the key
segment did not match the device. Used if the Key
Segment was contained in the path.
26 n/a Invalid path size
D0 01 Connection is closed or stopped
D0 02 Connection open is pending.
(Target connection) Nothing is talking to this
connection.
D0 03 Connection close is pending
Figure 5 Connection Status Values
Operating Status
The following registers contain information about the operation of the
MBCN.
Number of Instances
Register 15748 contains the number of connections currently configured.
This includes both originator-to-target (O=>T) and target-to-originator
(T=>O) connections.
Register 15751 contains the number of originator instances.
Overall Status
Register 15745 contains the overall status. You can use bits in this
register to quickly determine the overall status of MBCN operations.
If bit 0 is set, all I/O and scheduled consume and scanner (originator)
connections are operating with no errors.
If bit 8 is set, all scheduled produced (target) connections are operating
with no errors.
