Current Address
Register 9244 contains the value read from the thumbwheels at
power-up. If you change the thumbwheels after power-up, the value in
this register does not change.
MAC ID Switches
Register 9245 contains the value read from the thumbwheels at power-
up. If you change the thumbwheels after power-up, the value in this
register does not change.
Summary of ID Area Locations
Name Location Description
VendorID 9216 Module vendor ID
DeviceType 9217 Module device type
ProductCode 9218 Module product code
MajorRev 9219 Module major revision
MinorRev 9220 Module minor revision
Status 9221 Module status
SerialNum 9222-9223 Module serial number
ModChkPattern 9224 Always contains C9E2h
ProdNameLen 9227 Product name length, in bytes
ProdName 9228-9243 Product name, ASCII text
MacIdCurr 9244 Address read at power-up
MacIdSwitches 9245 Address read at power-up
Figure 30 ID Locations Table
