Page 62 AutoMax ControlNet Module
Publication number DSMBCN-UM001B-EN-P February 2003
Name Value 7-Segment
LED
KPR_STE_NET_CHANGE_FAULTED_MASTER 12 5
KPR_STE_DISABLED FFh N/A
Figure 21 Keeper State Table
To scan I/O, the keeper state must be KPR_STE_BACKUP or
KPR_STE_MASTER. Unscheduled messaging and scheduled produced
(target) connections will work in other keeper states.
Faulted states (faulted master or faulted backup) mean the keeper
configuration on the MBCN doesn’t match the network. Run
RSNetWorx and reschedule the network.
All other states are transitional.
Flash State
The FlashState register (9477) indicates the current state of the flash
memory, that is, whether the flash is currently being written to. Possible
values are:
Name Value
FLSH_STE_IDLE 00
FLSH_STE_WRITE 01
Figure 22 Flash Memory State Table
The flash is written when a new configuration is sent or when a new
schedule is written from RSNetWorx.
Serial CONFIG Port State
The Serial CONFIG State register (9466) shows the state of the serial
CONFIG port on the MBCN.
Value Meaning
0 The CONFIG port is idle, not being accessed
1 The CONFIG port is being accessed
2 A BSS file is being downloaded through the
CONFIG port
Figure 23 Serial Config State
