Page 54 AutoMax ControlNet Module
Publication number DSMBCN-UM001B-EN-P February 2003
Code, hex Description
16 Scanner not able to communicate with 1771
rack adapter
17 Adapter cannot communicate with module
18 1771 module response was not valid
19 Duplicated label
1A File is open; another node owns it
1B Another node is the program owner
1C-FF (not used)
Figure 14 Extended Status Error Codes Table
Commands from Remote Nodes
The module responds to the following incoming commands from remote
nodes:
Command Function Description
0F 68 Typed Read / Read Block
0F 67 Typed Write / Write Block
0F 01 Word Range Read / Read Block
0F 00 Word Range Write / Write Block
0F 26 Read-Modify-Write /Write Bit
Figure 15 Unsolicited PLC-5 Commands
For the PLC-5 commands shown, the module supports both logical
ASCII addresses and logical binary addresses.
The module accepts PLC-5 typed read, typed write, word range read and
word range write commands from ControlLogix PLCs.
