Using This Manual
Contents
Chapter Objectives 1–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Contents 1–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Intended Audience 1–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cautions 1–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Related Publications 1–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trademarks 1–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The objective of this chapter is to provide an overview of the contents and
organization of this manual, to describe the intended audience, and to list
related publications.
The contents of this manual are briefly described in Table 1.A below.
Table 1.A
Chapter Descriptions
Ch/App Title Description
1 Using This Manual Provides an overview of the manual.
2
Introduction to the
USER–PAK Option
Previews the main features and capabilities of
the USER–PAK option.
3 Installation
Describes how to install the USER–PAK
option into the CVIM module, and discusses
the use of the two memory cards.
4
Getting Started / Using
Security Levels
Describes how to access the setup mode, and
how to set up the different security levels.
5 Modifying the CVIM Menus
Describes how to delete menu items, and how
to modify the text of menu items.
6
Creating Custom Serial Port
Messages
Describes how to create custom messages for
transmission through a serial port.
7
Creating Custom Runtime
Displays
Describes how to create custom displays
which appear during runtime.
8
Defining Strings for Serial
Ports and Viewports
Describes how to enter string text, use valid
string elements, and set event and repetition
parameters for strings.
9 Using Copy and Paste
Describes how to use the Copy and Paste
functions to copy the settings directly from one
tool to another of the same type, copy one
string to another, or copy one viewport or
serial port to another.
10
Loading CVIM / USER–PAK
Configurations
Describes how to load specific portions of
CVIM / USER–PAK configurations.
A
Connecting and Using a
Mouse
Describes how to connect and use a mouse
for interfacing with the CVIM screen menus.
B Character Codes
Lists the ASCII characters and CVIM module
graphics characters that can be generated
within strings using the character codes.
C
ASCII Commands for the
USER–PAK Option
Describes the serial port ASCII commands
which apply specifically if the USER–PAK
option is installed.
Chapter Objectives
Manual Contents
