Example 6 – conditionally displaying a text string – Rockwell Automation 5370-UPK CVIM USER-PAK Option User Manual

Page 117

Chapter 8

Defining Strings for Serial Ports and Viewports

8–41

Example 6 – Conditionally Displaying a Text String

The “PART REJECTED” string in the viewport is conditionally displayed;
that is, it appears only when the master range fails (the part fails).

Example 6

In order to achieve this, we use literal text in the string code to create the
“PART REJECTED” message, then set the event

for the string, using the

Event

menu, so that the string is displayed whenever the master range fails.

In addition, since a

Text

viewport string is not automatically erased from

inspection to inspection, we need to create a second string, displayed in

Clear

text, in order to “erase” the PART REJECTED message when the

master range passes (the part passes). Otherwise, once PART REJECTED is
displayed, it remains on screen, even though parts are not failing inspections.

The string text for the PART REJECTED message is simply this:

In order to display the message only when the master range fails, we need to
set the

Event

menu so that

Master Range

and

Print on FAIL

are selected:

Event Menu

Print on FAIL selected
Master Range selected
