1 Publication 1753-UM001B-EN-P - November 2005
Chapter
4
Check, Download, Start, and Test a Routine
Using This Chapter
To download and run a routine, you must:
• Complete your system configuration and your routine logic.
• Save your logic by choosing Object>Save on the Project
Management menu bar.
• Generate code. Make sure all your system configuration is
complete before you generate code.
• Connect the programming terminal (running RSLogix Guard
PLUS! software) to the controller.
• Download the routine to the controller. See page 4-2.
• Start the routine. See page 4-4.
Check Consistency To determine whether or not you need to download your routine, you
can use the Check Consistency feature to verify whether the routine
running in the controller is the same routine you are editing in
RSLogix Guard PLUS! software. Choose Resource>Check Consistency
to compare the two programs. If all the codes match, your offline
routine has been previously downloaded to the controller.
For information about See page
checking consistency (whether you need to download your routine) 4-1
downloading a routine 4-2
starting a routine 4-4
testing a routine 4-5
how a routine executes 4-6
