Publication 1753-PM001A-EN-P - November 2005
Configure the GuardPLC OPC Server B-9
2. Choose File >Open.
3. Point to your opc.xml file and click Open.
4. The controller and the OPC Server should appear in the Root
window.
5. Click the Connect to HIPRO button.
6. Answer Yes to the query.
7. A connection opens between the G16OPC01 and the OPC
Server.
8. In the structure view, expand Root.
9. Expand G16OPC01.
10. Use the Export and Import icons to view input (DI1) and output
(DO1) data, respectively.
Root
Name
System
ID/SRS
Connection state
IP Addresses
G16OPC01
60000.1
Not connected
192.168.0.99, 127.0.0.1
OPC Server_1
1
Not connected
192.168.0.216, 127.0.0.1
Root
Name
System
ID/SRS
Connection state
IP Addresses
G16OPC01
60000.1
Connected on channel one
192.168.0.99, 127.0.0.1
OPC Server_1
1
Connected on channel one
192.168.0.216, 127.0.0.1
