A-2 Specifications
ArmorPoint DeviceNet Adapters - 1738-ADN12, -ADN18, -ADN18P, and -ADNX
DeviceNet Power Specifications
Power Supply
Note: In order to comply with CE Low Voltage Directives (LVD), you must use either a NEC Class
2, a Safety Extra Low Voltage (SELV) or a Protected Extra Low Voltage (PELV) power supply to
power this adapter. A SELV supply cannot exceed 30V rms, 42.4V peak or 60V dc under normal
conditions and under single fault conditions. A PELV supply has the same rating and is
connected to protected earth.
Input Voltage Rating
24V dc nominal
DeviceNet Input Voltage Range
11-25V dc DeviceNet specification
Input Overvoltage Protection
Reverse polarity protected
DeviceNet Power Requirements
24V dc (+4% = 25V dc) @ 30 mA maximum
Power Supply Specifications
Power Supply
Note: In order to comply with CE Low Voltage Directives (LVD), you must use either a NEC Class
2, a Safety Extra Low Voltage (SELV) or a Protected Extra Low Voltage (PELV) power supply to
power this adapter. A SELV supply cannot exceed 30V rms, 42.4V peak or 60V dc under normal
conditions and under single fault conditions. A PELV supply has the same rating and is
connected to protected earth.
Input Voltage Rating
24V dc
10-28.8V dc range
Input Overvoltage Protection
Reverse polarity protected
Inrush Current
6 A maximum for 10 ms
PointBus Output Current
1 A maximum @ 5V dc +5% (4.75-5.25)
Field Side Power Requirements, Maximum 24V dc (+20% = 28.8V dc) @ 400 mA
Interruption
Output voltage will stay within specifications when input drops out for 10 ms at 10V with
maximum load
General Specifications
LED Indicators
1 green/red Adapter status
1 green/red DeviceNet status
1 green/red PointBus status
1 green System Power (PointBus 5V power)
1 green Adapter Power (24V from field supply)
Power Consumption, Maximum
8.1 W @ 28.8V dc
Power Dissipation, Maximum
2.8 W @ 28.8V dc
Thermal Dissipation, Maximum
9.5 BTU/hr. @ 28.8V dc
Isolation Voltage
(continuous-voltage withstand rating)
50V rms
Tested at 1250V ac rms for 60 s
Field Power Bus
Nominal Voltage
Supply Voltage
Supply Current
24V dc
10-28.8V dc range
10 A maximum
Dimensions Inches) (Millimeters)
4.41 H x 2.83 W x 2.56 D (112 H x 72 W x 65 D)
Operating Temperature
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
20 to 60°C (68 to 140°F)
Storage Temperature
IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry Heat),
-40 to 85°C (-40 to 185°F)
