D-2 Default Data Maps
1738-IA2 Input Module
Message size: 1 Byte
1738-IB2 Sink Input Module
Message size: 1 Byte
1738-IB4 Sink Input Module
Message size: 1 Byte
7
6
5
4
3
2
1
0
Produces (scanner Rx)
Ch1
Ch0
Consumes (scanner Tx)
No consumed data
Where: Ch0 = channel 0, Ch1 = channel 1; 0 = OFF, 1 = ON
7
6
5
4
3
2
1
0
Produces (scanner Rx)
Ch1
Ch0
Consumes (scanner Tx)
No consumed data
Where: Ch0 = channel 0, Ch1 = channel 1; 0 = OFF 1 = ON
7
6
5
4
3
2
1
0
Produces (scanner Rx)
Ch3
Ch2
Ch1
Ch0
Consumes (scanner Tx)
No consumed data
Where: Ch0 = input channel 0, Ch1 = input channel 1, Ch2 = input channel 2, Ch3 = channel 3; 0 = OFF 1 = ON
