Rockwell Automation 1738-ADNX ArmorPoint I/O DeviceNet Adapters User Manual
Page 103

Publication 1738-UM001A-EN-P - February 2005
Quick Start For the 1738-ADNX B-29
14. Select the 1738-ADNX and then used the single right arrow key
to add it to your scanlist.
• Notice that you did not get the error message that you
received earlier, when you were told that the 1738-ADNX
ArmorPoint I/O DeviceNet Adapter does not contain any I/O
data.
• When you selected the Edit I/O Parameters button, you found
that no values were filled in the Input and Output fields.
• Now that you have looked at the Subnet, saved the
information, and associated the main network with the
Subnet, most of the information is now available from the
main network.
15. Select the 1738-ADNX in the Scanlist and then click Edit I/O
Parameters.
You might have more nodes on
your DeviceNet Network, but
only add the 1738-ADNX to the
scanlist as shown here.
Click to add available devices to
scanlist.
Click to download to the scanner.
Edit I/O Parameters button.
