1738-ow4 relay sink/source output module – Rockwell Automation 1738-ADNX ArmorPoint I/O DeviceNet Adapters User Manual
Page 116
Publication 1738-UM001A-EN-P - February 2005
D-6 Default Data Maps
1738-OV4E Protected Sink Output Module
Message size: 1 Byte
Message size: 1 Byte
1738-OW4 Relay Sink/Source Output Module
Message size: 1 Byte
7
6
5
4
3
2
1
0
Produces (scanner Rx)
Not used
Ch3
Ch2
Ch1
Ch0
Channel status
Where: Ch0 = output channel 0, Ch1 = output channel 1, Ch2 = output channel 2, Ch3 = output channel 3; 0 = no error 1 = error
7
6
5
4
3
2
1
0
Consumes (scanner Tx)
Not used
Ch3
Ch2
Ch1
Ch0
Channel state
Where: Ch0 = output channel 0, Ch1 = output channel 1, Ch2 = output channel 2, Ch3 = output channel 3; 0 = OFF 1 = ON
7
6
5
4
3
2
1
0
Consumes (scanner Tx)
Not used
Ch3
Ch2
Ch1
Ch0
Channel state
Where: Ch0 = output channel 0, Ch1 = output channel 1, Ch2 = output channel 2, Ch3 = output channel 3; 0 = OFF 1 = ON
