1738-oe2c analog current output module, 1738-oe2v analog output module – Rockwell Automation 1738-ADNX ArmorPoint I/O DeviceNet Adapters User Manual
Page 119

Publication 1738-UM001A-EN-P - February 2005
Default Data Maps D-9
1738-OE2C Analog Current Output Module
Message size: 4 bytes
Message size: 2 Bytes
1738-OE2V Analog Output Module
Message size: 2 Bytes
15
14
13
12
11
10
09
08
07
06
05
04
03
02
01
00
Consumes (Tx)
Output Channel 0 High Byte
Output Channel 0 Low Byte
Output Channel 1 High Byte
Output Channel 1 Low Byte
15
14
13
12
11
10
09
08
07
06
05
04
03
02
01
00
Produces (Rx)
High Byte - Channel 1 Status
Low Byte - Channel 0 Status
Not used
HCA
LCA
CM
CF
Not used
HCA
LCA
CM
CF
Where: CF = Channel Fault status; 0 = no error, 1 = fault
CM = Calibration Mode; 0 = normal, 1 = calibration mode
LCA = Low Clamp Alarm; 0 = no error, 1 = fault
HCA = High Clamp Alarm; 0 = no error, 1 = fault
15
14
13
12
11
10
09
08
07
06
05
04
03
02
01
00
Produces (scanner Rx)
Channel 1 Status - High Byte
Channel 0 Status - Low Byte
Not used
HCA
LCA
CM
ST
Not used
HCA
LCA
CM
ST
Where: ST = Channel Fault Status; 0 = no error, 1 = fault
CM = Calibration Mode; 0 = normal, 1 = calibration mode
LCA = Low Clamp Alarm; 0 = no error, 1 = fault
HCA = High Clamp Alarm; 0 = no error, 1 = fault
