Page 111

1
Publication 1738-UM001A-EN-P - February 2005
Appendix
D
Default Data Maps
I/O messages are sent to (consumed) and received from (produced)
the ArmorPoint I/O modules. These messages are mapped into the
processor’s memory. This appendix lists the default data maps for
1738 ArmorPoint I/O modules.
For the default data map of:
See page:
1738-OB2E Electronically Protected Output Module
1738-OB2EP Protected Output Module
1738-OB4E Electronically Protected Output Module
1738-OB8E Electronically Protected Output Module
1738-OV4E Protected Sink Output Module
1738-OW4 Relay Sink/Source Output Module
1738-IE2C Analog Current Input Module
1738-OE2C Analog Current Output Module
1738-OE2V Analog Output Module
1738-IJ Encoder/Counter Module
1738-IT2I Isolated Thermocouple Input Module
1738-VHSC 24V dc High Speed Counter Module
1738-SSI Synchronous Serial Interface Absolute Encoder Module
