Rockwell Automation Publication 1560E-UM051F-EN-P - June 2013 159
Appendix
B
Parameter Information
Parameter List
Table 32 - Parameter List
Group Parameter Description Parameter
Number
Units Min / Max Default
Settings
User
Settings
Metering Volts Phase A-B 1 V
Volts Phase B-C 2 V
Volts Phase C-A 3 V
Current Phase A 4 A
Current Phase B 5 A
Current Phase C 6 A
Watt Meter 7 KW/MW
Kilowatt Hours 8 KWH/MWH
Elapsed Time 9 Hours
Meter Reset 10 NO
ETM Reset
KWH Reset NO
Power Factor 11 0.00…0.99
Mtr Therm Usage 12 % 0…100
Motor Speed 13 % 0…100
Basic Set Up SMC Option 14 Standard Brake
Pump Control
Motor Connection 15 Line/Delta Line
(2)
(2) Do not set to “Delta”.
Line Voltage 16 V 0…10000 480
Starting Mode 17 Full Voltage
Current Limit
Soft Start
Linear Speed
Pump Start Soft Start
Ramp Time 18 SEC 0…30 10
Initial Torque 19 % LRT 0…90 70
Cur Limit Level 20 % FLC 50…600 350
Kickstart Time 22 SEC 0.0…2.0 0.0
Kickstart Level 23 % LRT 0…90 0
Option 2 Input
(1)
(1) Pump modules do not display this parameter. Default setting for MV applications is typically ‘Emergency Run’.
24 Disable
Preset SS
Dual Ramp
Fault
Fault NC
Network
Clear Fault
Emergency Run Disable
Dual Ramp Starting Mode 2 25 Full Voltage
Current Limit
Soft Start
Linear Speed Soft Start
Ramp Time 2 26 SEC 0…30 10
Initial Torque 2 27 % LRT 0…90 70
Cur Limit Level 2 28 % FLC 50…600 350
Kickstart Time 2 30 SEC 0.0…2.0 0.0
Kickstart Level 2 31 % LRT 0…90 0
