Chapter 1
Product Overview
an existing or OEM/customer-supplied starter. It is comprised of several modular
components, including:
•
Frame-mounted or loose power stacks including gate driver boards
•
Loose interface and voltage feedback boards
•
Fiber optic cables for SCR firing
•
Microprocessor based control module
•
Bypass vacuum contactor
1560E – Retrofit Controller
A medium voltage solid-state controller designed to work in conjunction with an
existing customer-supplied starter. It includes:
•
Tin-plated, copper, horizontal power bus (optional)
•
A continuous, bare copper ground bus
•
Power electronics
•
A bypass vacuum contactor
•
Three (3) current transformers
•
A low voltage control panel complete with microprocessor-based control
module
•
Top and bottom plates to accommodate power cables.
1562E – Combination Controller
A medium voltage solid-state controller that provides isolation and protection
for new installations. It includes:
•
Tin-plated, copper, horizontal power bus (optional)
•
A continuous, bare copper ground bus
•
Power electronics
•
A main non-load-break isolating switch and operating handle
•
An isolation vacuum contactor
•
A bypass vacuum contactor
•
Three (3) current limiting power fuses for NEMA Class E2 operation
•
Three (3) current transformers
•
A control power transformer (optional)
•
A low voltage control panel complete with microprocessor-based control
module
•
Space for necessary auxiliary control and metering devices
•
Top and bottom plates to accommodate power cables
•
Motor overload protection (included in SMC Flex control module)
TIP
Interlocking on page 49 of Chapter 2
.
