90 Rockwell Automation Publication 1560E-UM051F-EN-P - June 2013
Chapter 6 Options
Pump Control
Pump Control The green start button, when pressed, will commence
motor acceleration to full speed.
The red stop button, when pressed, will provide a coast
stop, and/or reset a fault.
The jog button, when pressed, will initiate a pump stop
maneuver.
Braking Control
(1)
Smart Motor Braking The green start button, when pressed, will commence
motor acceleration to full speed.
The red stop button, when pressed, will provide a coast
stop, and/or reset a fault.
The jog button, when pressed, will initiate a brake stop.
Accu-Stop The green start button, when pressed, will commence
motor acceleration to full speed.
The red stop button, when pressed, will provide a coast
stop, and/or reset a fault.
With a “stopped” status, the jog button, when pressed,
will initiate slow speed motor operation. From an “at
speed” condition, the jog button, when pressed, will
initiate braking to slow speed operation. The controller
will maintain slow speed operation as long as the jog
button is pressed.
Slow Speed with Braking The green start button, when pressed, will commence
motor acceleration to full speed.
The red stop button, when pressed, will provide a coast
stop, and/or reset a fault.
The jog button will initiate a brake stop.
* Slow Speed cannot be operated via the HIM.
(1) Braking Control is not offered for standard use in MV applications. Please consult factory for further assistance.
ATTENTION: The Bulletin 20-HIM interface module’s stop push button is not
intended to be used as an emergency stop. Refer to the applicable standards for
emergency stop requirements.
Option Action Operation
II
O O
Sel Jog
II
O O
Sel Jog
II
O O
Sel Jog
II
O O
Sel Jog
