Rockwell Automation Publication 1560E-UM051F-EN-P - June 2013 1
Chapter
1
Product Overview
Manual Objectives This manual is intended for use by personnel familiar with Medium Voltage and
solid-state power equipment. The manual contains material which will allow the
user to operate, maintain and troubleshoot the MV SMC™ Flex family of
controllers. The family consists of the following Bulletin numbers: 1503E, 1560E
and 1562E.
See Appendix D , Appendix E and Appendix F for arc-resistant cabinets.
Documentation The following Rockwell Automation publications provide pertinent information
for the MV SMC Flex and components:
• MVB-5.0 General Handling Procedures for MV
Controllers
• 1500-UM055_-EN-P Medium Voltage Controller Two-High Cabinet
(200A/400A) – User Manual
• 1502-UM050_-EN-P 400A Vacuum Contactor, Series D
– User Manual
• 1502-UM052_-EN-P 400A Vacuum Contactor, Series E
– User Manual
• 1502-UM051_-EN-P 800A Vacuum Contactor, Series D and E
– User Manual
• 1560E-SR022_-EN-P Medium Voltage SMC Flex Controllers
– General Specifications
• 1503-UM051_-EN-P IntelliVAC Contactor Control Module
Description The MV SMC Flex is a solid-state, three-phase, AC line controller. It is designed
to provide microprocessor-controlled starting and stopping of standard
three-phase, squirrel-cage induction motors, using the same control module as
the Allen-Bradley Bulletin 150 SMC Flex.
1503E – OEM Controller
A chassis-mount medium voltage solid-state controller designed to mount in an
OEM or customer-supplied structure, and designed to work in conjunction with
TIP This user manual pertains to units with Series letter K or later, and firmware
release 4.xxx (or later).
