154 Rockwell Automation Publication 1560E-UM051F-EN-P - June 2013
Appendix A Specifications
Table 28 - Shipping Weights and Dimensions
(1)
Current
Rating Horsepower (kW) Dimensions in inches (mm) Shipping Weight
2400 V 3300 V 4200 V 6600 V 6900 V Width Depth Height lb kg
Bulletin 1560E
200 A 800
(600) 1000
(746) 1250
(933) – – 26
(660) 36
(915) 91
(2315) 800 363
400 A 1500
(1119) 2250
(1679) 2750
(2051) – –
Bulletin 1560E
200 A – – – 2250
(1678) 2500
(1865) 36
(915) 36
(915) 91
(2315) 1220 554
400 A – – – 4500
(3357) 5000
(3730)
600A
(top exit) 2750
(2051) 4000
(2984) 4500
(3357) 7500
(5595) 7500
(5595) 44
(1117) 36
(915) 36
(915) 1330 590
600 A
(bottom exit) 2750
(2051) 4000
(2984) 4500
(3357) 7500
(5595) 7500
(5595) 70
(1778) 36
(915) 91
(2315) 2100 951
Bulletin 1562E
200 A 800
(600) 1000
(746) 1250
(932) – – 46
(1168)
(2)
36
(915) 91
(2315)
or
128.5
(3264)
(2)
1400
or
1950
(2)
636
or
886
(2)
400 A 1500
(1119) 2250
(1679) 2750
(2051) – –
Bulletin 1562E
200 A – – – 2250
(1676) 2500
(1865) 62
(1575) 36
(915) 91
(2315) 2325 1056
400 A – – – 4500
(3357) 5000
(3730)
Bulletin 1562E
600 A 2750
(2051) 4000
(2984) 4500
(3357) 7500
(5600) 7500
(5600) 80
(2032) 36
(915) 91
(2315) 2700 1227
>2750
(2051) >4000
(2984) >4500
(3357) >7500
(5600) >7500
(5600) 100
(2540) 36
(915) 91
(2315) 4000 1816
(1) Weights and dimensions are approximate. Certain options (such as PFCC) will change weight and dimensions. Contact factory for certified dimensions and weights.
(2) Additional dimensions/weights shown are for arc resistant version.
