Rockwell Automation Publication 1560E-UM051F-EN-P - June 2013 153
Specifications Appendix A
Table 26 - Altitude Derating
Table 27 - Area Available for Cable Entry/Exit
Dimensions are in inches (mm).
Environmental Ratings UL/CSA/NEMA IEC
Operating Temperature Range 0°C to 40°C (32°F to 104°F)
Storage and Transportation Temperature Range -20°C to +75°C (-4°F to 149°F)
Altitude 0 - 1000 meters (3,300 feet) without derating (2)
Humidity 5% to 95% (non condensing)
Pollution Degree 2
Seismic (UBC Rating) (1) 1, 2, 3, 4
(1) Some units may require special bracing. Contact factory for more information.
(2) Starter Deratings are in
Table 26 .
Altitude Range Power Cell Rating
(1)
(1) Current deratings shown are the minimum levels. Additional derating may be required due to power fuse limitations. Please consult factory for additional details.
Reduce B.I.L.
Withstand Rating By:
180 A 360 A 600 A
1,000 to 2,000 m
(3,300 to 6,600 ft) Reduce Max. Continuous Current Rating by: 6.0 kV
10 A 10 A 15 A
2,001 to 3,000 m
(6,601 to 9,900 ft) 20 A 20 A 30 A 12.0 kV
3,001 to 4,000 m
(9,901 to 13,200 ft) 30 A 30 A 45 A 18.0 kV
4,001 to 5,000 m
(13,201 to 16,500 ft) 40 A 40 A 60 A 24.0 kV
StructureCode Voltage Top Bottom
Line Load Line Load
14.60 2300 – 4160 V 5.68 X 9.00
(144 X 229) Combined with line 5.68 X 9.00
(144 X 229) Combined with line
14.62 6900 V 5.68 X 12.55
(144 X 319) Combined with line 5.68 X 12.55
(144 X 319) 5.68 X 12.55
(144 X 319)
14.64 All 5.68 X 12.55
(144 X 319) Combined with line NA NA
14.66 All 5.68 X 12.55
(144 X 319) Combined with line 15.00 x 15.00
(381 x 381) Combined with line
14.70 2300 – 4160 V 5.68 X 5.68
(144 X 144) 5.68 X 9.00
(144 X 229) 5.68 X 9.00
(144 X 229) 5.68 X 9.00
(144 X 229)
14.70XP 2300 – 4160 V 5.68 X 5.68
(144 X 144) 5.00 X 9.00
(144 X 229) 5.68 X 9.00
(144 X 229) 5.68 X 9.00
(144 X 229)
14.72 6900 V 5.68 X 9.00
(144 X 229) 5.68 X 9.00
(144 X 229) 5.68 X 5.68
(144 X 144) 5.68 X 9.00
(144 X 229)
14.74 2300 – 4160 V 5.68 X 9.00
(144 X 229) 5.68 X 9.00
(144 X 229) 5.68 X 9.00
(144 X 229) 5.68 X 9.00
(144 X 229)
14.76 All 5.68 X 9.00
(144 X 229) 7.25 X 15.88
(184 X 403) 5.68 X 9.00
(144 X 229) 7.25 X 15.88
(184 X 403)
