Refer to the PowerFlex 40P User Manual supplied with the drive for
complete listing of parameters.
P037 [Stop Mode] 0/9 0 = “Ramp, CF” (1)
1 = “Coast, CF” (1)
2 = “DC Brake, CF” (1)
3 = “DCBrkAuto,CF” (1)
4 = “Ramp”
5 = “Coast”
6 = “DC Brake”
7 = “DC BrakeAuto”
8 = “Ramp+EM B,CF”
9 = “Ramp+EM Brk”
(1) Stop input also clears active fault.
0
Active stop mode for all stop sources [e.g. run
forward (I/O Terminal 02), run reverse (I/O
Terminal 03), RS485 port] except as noted.
Important:
I/O Terminal 01 is always a coast to
stop input except when P036 [Start Source] is set
for “3-Wire” control. When in three wire control, I/O
Terminal 01 is controlled by P037 [Stop Mode].
P038 [Speed Reference] 1/9 1 = “InternalFreq”
2 = “0-10V Input”
3 = “4-20mA Input”
4 = “Preset Freq”
5 = “Comm Port”
6 = “Stp Logic”
7 = “Anlg In Mult”
8 = “Encoder”
9 = “Positioning”
5
Sets the source of the speed reference to the
drive.
Important:
When A051 or A052 [Digital Inx Sel] is
set to option 2, 4, 5, 6, 13 or 14 and the digital
input is active, A051, A052, A053 or A054 will
override the speed reference commanded by this
parameter. Refer to Chapter 1 of the PowerFlex
40P User Manual for details.
P039 [Accel Time 1] 0.0/600.0 Secs 0.1 Secs 10.0 Secs
Sets the rate of accel for all speed increases.
P040 [Decel Time 1] 0.0/600.0 Secs 0.1 Secs 10.0 Secs
Sets the rate of decel for all speed decreases.
P041 [Reset To Defalts] 0/1 0 = “Ready/Idle”
1 = “Factory Rset”
0
Resets all parameter values to factory defaults.
P042 [Voltage Class] 2/3
2 = “Low Voltage” (480V)
3 = “High Voltage” (600V)
3
Sets the voltage class of 600V drives.
P043 [Motor OL Ret] 0/1 1 = “Enabled” 0 = “Disabled”
Enables/disables the Motor Overload Retention function.
= Stop drive before changing this parameter.
No. Parameter Min/Max Display/Options Default
Advanced Display Group Parameters
No. Parameter Min/Max Display/Options
d301 [Drive Status 2] 0/1 1
d302 [Fibers Status] 0/1 1
d303 [Slip Hz Meter] 0.0/25.0 Hz 0.1 Hz
d304 [Speed Feedback] 0/64000 RPM 1 RPM
d305 [Speed Feedback F] 0.0/0.9 0.1
d306 [Encoder Speed] 0/64000 1
d307 [Encoder Speed F] 0.0/0.9 0.1
d308 [Units Traveled H] 0/64000 1
d309 [Units Traveled L] 0.00/0.99 0.01
Program Group Parameters
