English-17
The PowerFlex 40P is designed so that start up is simple and efficient. The Program Group
contains the most commonly used parameters.
Display Group Parameters
No. Parameter Min/Max Display/Options
b001 [Output Freq] 0.00/[Maximum Freq] 0.01 Hz
b002 [Commanded Freq] 0.00/[Maximum Freq] 0.01 Hz
b003 [Output Current] 0.00/(Drive Amps × 2) 0.01 Amps
b004 [Output Voltage] 0/Drive Rated Volts 1 VAC
b005 [DC Bus Voltage] Based on Drive Rating 1 VDC
b006 [Drive Status] 0/1 (1 = Condition True) Bit 3 Bit 2 Bit 1 Bit 0
Decelerating Accelerating Forward Running
b007-
b009
[Fault x Code] F2/F122 F1
b010 [Process Display] 0.00/9999 0.01 – 1
b012 [Control Source] 0/112 Digit 2&3 = Speed Command Digit 1 = Start Command
(See P038; 9 = “Jog Freq”) (See P036; 9 = “Jog”)
b013 [Contrl In Status] 0/1 (1 = Input Present) Bit 3 Bit 2 Bit 1 Bit 0
DB Trans On Stop Input Dir/REV In Start/FWD In
b014 [Dig In Status] 0/1 (1 = Input Present) Bit 3 Bit 2 Bit 1 Bit 0
Digital In 4 Digital In 3 Digital In 2 Digital In 1
b015 [Comm Status] 0/1 (1 = Condition True) Bit 3 Bit 2 Bit 1 Bit 0
Comm Error DSI Option Transmitting Receiving
b016 [Control SW Ver] 1.00/99.99 0.01
b017 [Drive Type] 1001/9999 1
b018 [Elapsed Run Time] 0/9999 Hrs 1 = 10 Hrs
b019 [Testpoint Data] 0/FFFF 1 Hex
b020 [Analog In 0-10V] 0.0/100.0% 0.1%
b021 [Analog In 4-20mA] 0.0/100.0% 0.1%
b022 [Output Power] 0.00/(Drive Power × 2) 0.01 kW
b023 [Output Powr Fctr] 0.0/180.0 deg 0.1 deg
b024 [Drive Temp] 0/120 degC 1 degC
b025 [Counter Status] 0/9999 1
b026 [Timer Status] 0.0/9999 Secs 0.1 Secs
b028 [Stp Logic Status] 0/8 1
b029 [Torque Current] 0.00/(Drive Amps × 2) 0.01 Amps
Smart Start-Up with Basic Program Group Parameters
= Stop drive before changing this parameter.
No. Parameter Min/Max Display/Options Default
P031 [Motor NP Volts] 20/Drive Rated Volts 1 VAC Based on Drive Rating
Set to the motor nameplate rated volts.
P032 [Motor NP Hertz] 15/500 Hz 1 Hz 60 Hz
Set to the motor nameplate rated frequency.
P033 [Motor OL Current] 0.0/(Drive Rated Amps × 2) 0.1 Amps Based on Drive Rating
Set to the maximum allowable motor current.
P034 [Minimum Freq] 0.00/500.0 Hz 0.01 Hz 0.00 Hz
Sets the lowest frequency the drive will output
continuously.
P035 [Maximum Freq] 0.00/500.0 Hz 0.01 Hz 60.00 Hz
Sets the highest frequency the drive will output.
P036 [Start Source] 1/6 1 = “3-Wire”
2 = “2-Wire”
3 = “2-W Lvl Sens”
4 = “2-W Hi Speed”
5 = “Comm Port”
6 = “Momt FWD/REV”
5
Sets the control scheme used to start the drive.
