Lenze L-force I/O System 1000 - Manual (Page 76)

L-force Controls | I/O System 1000
Networking via CAN system bus
Port assignment
76
L
2.0 EN - 11/2010
1) The bits are set until reset with RES_SET (bit 6 control word).
EPM-S603 Status word
Bit Designation Function
0 – Reserved
1 – Reserved
2 STS_SW-GATE Software gate status (set if SW gate active)
3 – Reserved
4 – Reserved
5 STS_GATE Status of internal gate (set if internal gate active)
6 – Reserved
7 STS_C_DN Status set for counter direction backwards
8 STS_C_UP Status set for counter direction forwards
9 – Reserved
10 – Reserved
11 STS_OFLW 1) Status set in the case of overflow
12 STS_UFLW 1) Status set in the case of underflow
13 STS_ZP 1) Status set in the case of zero crossing
14 – Reserved
15 – Reserved
EPM-S603 Control word
Bit Designation Function
0 – Reserved
1 – Reserved
2 SW_GATE_SET Sets the software gate
3 ... 5 – Reserved
6 RES_SET Resets the following bits with a 0-1 edge:
STS_CMP, STS_END, STS_OFLW, STS_UFLW and STS_ZP
7 ... 9 – Reserved
10 SW_GATE_RESET Resets the software gate
11 ... 15 – Reserved
