L-force Controls | I/O System 1000
Parameter setting
Electronic modules - analog output
Legend Description Index
Accept module
parameter
Changed settings will not be accepted until the function has been executed.
Click the input field to open the drop down menu.
• 255: Accept module parameters
0x31FF
Channel status Display of the current output signal of 0 ... 10 V. 0x6411
Signal function Signal function of the channel.
Click the input field to open the drop down menu.
• 16: 0...10V /0...27648dec
–Voltage signal output of 0 ... 10 V and a resolution of 0 ... 27648.
–The value range is displayed in the object.
• 32: 0...10V /0...16384dec
–Voltage signal output of 0 ... 10 V and a resolution of 0 ... 16384.
–The value range is displayed in the object.
• 255: Channel deactivated
–No output of a voltage signal
0x31xx
Error state selection Response of the channel to an error.
Click the input field to open the drop down menu.
• Last channel status is maintained
–The voltage signal remains on the value output last.
• Channel status = status in event of error
–The voltage signal is set to the value defined in the "Error state".
0x6443
Error state Response of the channel to an error if the "Channel status = status in event
of error" has been set in the "Error state selection".
Click the input field to open the drop down menu.
• Input of a voltage value (0 ... 10 V) that is to be output.
0x6444
