Parameter setting
Electronic modules - counters
48
L
2.0 EN - 11/2010
Start value Selection of a count value (max. 32 bits) where the counting process is to be
started.
Final value Selection of a count value (max. 32 bits) where the counting process is to be
stopped.
Set value
Hysteresis
Hysteresis for the prevention of frequent switching operations of the output
and triggering the alarm if the count value is in the range of the comparison
value. The hysteresis affects zero crossing, overflow, underflow, and
comparison value.
Adjustable range:
0 {1} 255
• The hysteresis is deactivated with "0" and "1".
Output pulse
duration
If the comparison value is reached, output 6 of the counter module is set for
the selected pulse duration.
Adjustable range:
0 {1} 255
0 {2.048 ms} 522.24 ms
• "0": The output is set until the comparison condition is no longer met.
• If a main counting direction has been set, the output is only switched if
the comparison value is reached from the main counting direction.
Current count value Display of the current count value

Note!
A description of the indexes for the paramter setting is provided in the I/O
system 1000 system manual.
Legend Description Index
