8 Technical data 97 2014-05-01
Note: Because of the high response accuracy, only use thermowells (pockets) that are included in the scope of delivery.
Actual type designation Old type
designation Probe type Temperature range Nom. length mm P rocess connection
RTD temperature probe Data Sheet 90.2006
902006/53-505-2003-1-12-190-815/000 90D239-F03 2 x Pt100 -40 ... +400 °C 190
902006/53-507-2003-1-12-100-815/000 90.239-F02 2 x Pt100
(arranged one
below the other
in protection tube) -40 ... +480 °C 100
902006/53-507-2003-1-12-160-815/000 90.239-F12 160
902006/53-507-2003-1-12-190-815/000 190
902006/53-507-2003-1-12-220-815/000 90.239-F22 220
902006/53-507-1003-1-12-100-815/000 90.239-F01 1 x Pt100 -40 ... +480 °C 100 weld-in sleeve
902006/53-507-1003-1-12-160-815/000 90.239-F11 160
902006/53-507-1003-1-12-220-815/000 90.239-F21 220
902006/53-505-1003-1-12-190-815/000 90.239-F03 1 x Pt100 -40 ... +400 °C 190
902006/53-505-3003-1-12-100-815/000 90.239-F07 3 x Pt100 -40 ... +400 °C 100
902006/53-505-3003-1-12-160-815/000 90.239-F17 160
902006/53-505-3003-1-12-220-815/000 90.239-F27 220
902006/40-226-1003-1-12-220-815/000 90.280-F30 1 x Pt100 -170 ... +480°C 220 weld-in sleeve
902006/40-226-1003-1-12-160-815/000 90.280-F31 160
902006/40-226-1003-1-12-100-815/000 90.280-F32 100
Thermocouples Data Sheet 90.1006
901006/53-543-1042-12-220-815/000 90.111-F01 1 x Fe-CuNi Type „L“ -35 ... 480°C 220 weld-in sleeve
901006/53-543-2042-12-220-815/000 90.111-F02 2 x Fe-CuNi Type „L“ 220
