7 Configuration level

2014-05-01

7.5.5

Error signal

If, for the measured value 1 or 2, the value is exceeded,

not reached, or a diagnostic error occurs, the current or

voltage value set on the analog output is output as a

so-called error signal.
For signal type 4 to 20 mA

3.4

or 21.2 mA

For signal type 0 to 20 mA

or 21.2 mA

For signal type 2 to 10 V

1.7

or 10.4 V

For signal type 0 to 10 V

or 10.4 V

Parameter

Comment

Value range
(factory-setting in bold)
