6 Safety Manual
40
Lambda:
λ
SU
Rate of undetected safe failures per hour
BPCS
Basic Process Control System
DC
D
iagnostic Coverage
FIT
Failures In Time (1x10
-9
per h)
HFT
Hardware Fault Tolerance
PFD
Probability of Failure on Demand
PFD
avg
Average Probability of Failure on Demand
MooN
Architecture with M from N channels
MTBF
Mean Time Between Failures
MTTR
Mean Time To Repair
SFF
Safe Failure Fraction
SIL
Safety Integrity Level
Name
Description
