14 Output behavior 2014-05-01 114
Differential – Alarm inactive again (STB function) Inactive
Unlocking possible Pre-alarm moni-
toring active
v Chapter
7.3.4
Scaled analog signal is
being output
v Chapter 7.5
After acknowledgement probe break – Alarm (STB
function)
Monitoring of the limit
value active
v Chapter 7.3.2
Internal errors
Internal errors diagnostic channel active Inactive Pre-alarm moni-
toring active
v Chapter
7.3.4
Scaled analog signal is
being output
v Chapter 7.5
Internal errors diagnostic channel inactive again Monitoring of the limit
value active
v Chapter 7.3.2
Internal errors safety channel active (STB) Inactive Active Error signal is being out-
put
v Chapter 7.5.5
Internal errors safety channel inactive again (STB) Inactive
Unlocking possible Pre-alarm moni-
toring active
v Chapter
7.3.4
Scaled analog signal is
being output
v Chapter 7.5
Internal errors safety channel after
acknowledgement (STB)
Monitoring of the limit
value active
v Chapter 7.3.2
Operating status Relay output alarm Relay output
pre-alarm KV Analog output
