ETC Matrix MkII Dimming System User Manual
Page 6
Table of Contents
1
I n t r o d u c t i o n
Congratulations...
on the purchase of an ETC Matrix® MkII system. Matrix MkII continues ETC's
tradition of providing the highest quality products for the entertainment lighting
market.
Using this Manual
This manual describes the general operation and programming information for the
Matrix Mk.II dimming system. Installation, maintenance and servicing details are
available in separate manuals. Owing to the range of options available, this user
manual may describe modules and features which are not directly relevant to a
specific installation.
The following symbols are used in this manual to alert you to danger or important
information.
Note: Provides important information about your installation
CAUTION: Alerts you to important information relating to equipment performance or reliability.
WARNING: RISK OF ELECTRIC SHOCK! warns you when electricity may cause injury.
WARNING: warns you where there isd the possibility of other types of injury.
