14
BACKUP: fades to dimmer levels set-up through the PRESETS memory facility
5 Press SAVE to leave the menu and record the changes or CANCEL (to leave
the previous settings unchanged and to return to the previous screen).
6. Repeat the procedure for DMX-2.
Note: If BACKUP has been set, do not forget to pre-set the relevant DMX backup states.
To set-up DMX Backup preset:
1. Select PRESETS. from the home menu
2. Press DOWN or UP or use the rotary encoder to choose DMX BACKUP menu.
Press SELECT.
3. The screen provides the following information:
SELECT DMX BACKUP DEVICE 12
CHANNEL 1
DMX-1 ADDRESS 005
DOWN UP EDIT CANCEL SAVE
4. Press EDIT and using the <<<< and >>>> buttons, choose the channel level to
be adjusted [enabled when square brackets are shown] and set the level by
using the rotary encoder.
5. Use the UP or DOWN button to address either DMX-1 or DMX-2 and repeat the
above procedure.
6. Press ENTER to leave the menu, then either SAVE (to record the changes) or
CANCEL (to leave the previous settings unchanged).
To set-up a DMX Minimum reset
In order to reduce dynamic filament noise in 120V Par lamps or to increase the rate
of response of high wattage filaments, it is sometimes necessary to use a low
preheat level. DMX minimum reset is an automatic means to reduce energy
consumption by switching off any preheat levels when DMX is not present (i.e. when
the control desk is switched off, but the dimmers remain on).
1. Select INSTALL from the home menu.
2. Press DOWN or UP or use the rotary encoder to choose GENERAL SETTINGS
menu. Press SELECT.
3. Press DOWN or UP or use the rotary encoder to choose DMX MINIMUM
RESET menu. Press SELECT.
GENERAL SETTINGS
DMX MINIMUM RESET: [OFF]
DOWN UP CANCEL SAVE
4. Use the rotary encoder to choose either ON (active) or OFF (disabled).
