10
C h a p t e r 3
C o n f i g u r a t i o n P r o c e d u r e s
Initial settings
Some settings for the Matrix rack are made during installation only, and many of the
channel configuration settings may only rarely be changed after the commissioning
period. Some other settings may be changed regularly on a show-by-show basis
(e.g. non-dim operation).
The initial settings required are to program the processor to search for a particular
number of Matrix ‘devices’ in each rack, and to choose the power ratings for each
Matrix device.
To check the number of modules (devices) programmed for use in the rack:
This menu defines the number of modules in use in the rack, and is set at the time of
installation.
1. Select INSTALL from the home screen
2. Press DOWN or UP or use the rotary encoder to choose SELECT NUMBER OF
DEVICES menu. Press SELECT.
3. The screen shows
SELECT NUMBER OF DEVICES
DEVICES: 012
CANCEL ENTER
4. Use the rotary encoder to select the number of Matrix devices (the plug-in
modules) in the rack.
5. Press ENTER (to record the changes and return to the home screen) or CANCEL
(to leave the previous settings unchanged, and return to the home screen).
To select the load ratings of devices:
CAUTION: This feature sets the configuration of each dimmer module in the rack to define the
number of dimmers to be addressed and anticipated load and current measurements. If the
setting is incorrect, e.g. a 2 x 5kW dimmer is set up as a 1 x 12kW dimmer, the result will be two
adjacent channels operating as one.
This function is only available for the modules 4x3kW and 2x5kW sine wave
1. Activate a module (e.g. 12) by pressing its front panel access button (the
technology logo above the device’s column of LEDs). Or select the device with
the rotary encoder
2. Press DOWN or UP or use the rotary encoder to choose LOAD SELECTION
menu in the . Press SELECT.
3. The screen shows:
