CONFIGURE CHANNEL PARAMETERS
CH T-IN T-OUT CURVE I/O PRIOR PHASE MODE
ALL 00.05 00.05 LIN NO NO OFF [BASIC]
<<<< >>>> CANCEL SAVE
3. Use the <<<< and >>>> buttons, choose MODE [enabled when square brackets
are shown] and set it to:
BASIC, SOFT START, BURST, PROPortional or BLINK
4. Using the UP and DOWN buttons to address other channel numbers (unless all
dimmers are being set-up together).
5. Press ENTER to leave the menu, then either SAVE (to record the changes) or
CANCEL (to leave the previous settings unchanged).
Note: If BLINK has been set, be sure to adjust the T-IN and T-OUT times to create the required
flash characteristic, and adjust the DMX value when used for the period of flash.
Passwords
Passwords are used at 4 levels of the Matrix dimmer set-up procedure: SET-DMX,
PRESETS, CONFIG. and INSTALL. One password or 4 separate passwords may be
used to give a range of access options. Passwords are in the form of 4 digit codes
and may be set and used from the front panel of the dimmer and DimSTAT, but
passwords may only be read using DimSTAT. Passwords set at 0000 give unlimited
access.
Note: If the password is set to 0000 (factory default) the menus are open, and no prompts to
enter a password are seen on the display.
To set-up passwords:
1. Select INSTALL from the home menu
2. Press DOWN or UP or use the rotary encoder to choose SELECT NEW
PASSWORD menu. Press SELECT.
3. The screen is similar to this (passwords shown as example only).
SELECT NEW PASSWORD
SET-DMX PRESETS CONFIG INSTALL
PASSWORD [3589] 1478 9632 8520
EDIT CANCEL SAVE
4. Press EDIT and using the <<<< and >>>> buttons, choose the password to be
altered or set [enabled when square brackets are shown] and adjust the digits
using the rotary encoder.
5. Press ENTER to leave the menu, then either SAVE (to record the changes) or
CANCEL (to leave the previous settings unchanged).
