5. Use the rotary encoder to choose the address number and press >>>> or <<<<
to tab other 3-digit groups.
6. Press ENTER to leave the menu, then either SAVE (to record the changes) or
CANCEL (to leave the previous settings unchanged).
To set-up the merger gateway address:
1. Select INSTALL from the home menu
2. Press DOWN or UP or use the rotary encoder to choose MERGER ETHERNET
SETUP menu. Press SELECT.
3. This accesses the Merger’s Ethernet menu tree. Press DOWN or UP or use the
rotary encoder to choose GATEWAY ADDRESS menu. Press SELECT.
4. The screen shows:
SELECT ETHERNET GATEWAY ADDRESS
AAA BBB CCC DDD
IP ADDRESS [010] 001 001 001
<<<<< >>>>>> EDIT CANCEL SAVE
7. Use the rotary encoder to choose the address number and press >>>> or <<<<
to tab other 3-digit groups.
8. Press ENTER to leave the menu, then either SAVE (to record the changes) or
CANCEL (to leave the previous settings unchanged).
To set-up the merger universes:
1. Select INSTALL from the home menu
2. Press DOWN or UP or use the rotary encoder to choose MERGER ETHERNET
SETUP menu. Press SELECT.
3. This accesses the Merger’s Ethernet menu tree. Press DOWN or UP or use the
rotary encoder to choose NET, UNIVERSE A menu. Press SELECT.
4. The screen shows:
MERGER LOGIC NET, UNIVERSE A
NET UNIVERSE
0 000
EDIT CANCEL SAVE
5. Press EDIT and use the rotary encoder to choose the required logical net and
universe.
6. Press ENTER to leave the menu, then either SAVE (to record the changes) or
CANCEL (to leave the previous settings unchanged).
7. Repeat for Universe B.
