Note: All menu actions, except for INFO, are prefixed with the request to ENTER PASSWORD
if passwords are set greater than 0000
Preset and manual control functions
The Matrix Mk.II system has a total of 7 digital switch functions which can be
accessed through RS485 touch-panels. Options include fading or switching to a
preset state. The setting up is in two steps; capturing the dimmer levels and setting
the switch functions.
To set-up digital switch presets:
1. Set the dimmers to the require preset levels from the control desk.
2. Select PRESETS. from the home menu
3. Press DOWN or UP or use the rotary encoder to choose PRESETS STORE.
menu. Press SELECT.
4. The screen display shows:
STORE PRESET LEVELS
PRESET NUMBER: 01
STORE HOME
5. Press STORE to capture the levels and record them with the preset number
displayed, or press HOME to return to the previous screen.
To set-up digital switch functions:
1. Select PRESETS from the home menu.
2. Press DOWN or UP or use the rotary encoder to choose PRESETS CONFIG.
menu. Press SELECT.
3. The screen shows the 7 inputs IN-1 to IN-7 in a column with T-IN and T-OUT
settings, and a Normally Open (NO) and Normally Closed (NC) input switch
option.
ENTER PRESET CONFIGURATION
PRESET T-IN T-OUT
PRESET-1 000.0 000.0
DOWN UP EDIT CANCEL SAVE
4. Press EDIT and using the <<<< and >>>> buttons, choose the function to be
adjusted [enabled when square brackets are shown] and set the time and mode
by using the rotary encoder
5. Use the UP and DOWN buttons to address other presets and repeat the above
steps.
6. Press ENTER to leave the menu, then either SAVE (to record the changes) or
CANCEL (to leave the previous settings unchanged).
