2. Press DOWN or UP or use the rotary encoder to choose ETHERNET SETUP
menu. Press SELECT.
3. This accesses the Ethernet menu tree. Press DOWN or UP or use the rotary
encoder to choose IP ADDRESS menu. Press SELECT.
4. The screen shows:
SELECT ETHERNET ADDRESS
AAA BBB CCC DDD
IP ADDRESS [010] 001 002 002
<<<<< >>>>>> EDIT CANCEL SAVE
5. Use the rotary encoder to choose the address number and press >>>> or <<<<
to tab other 3-digit groups.
6. Press ENTER to leave the menu, then either SAVE (to record the changes) or
CANCEL (to leave the previous settings unchanged).
To set-up the dimmer subnet mask:
1. Select INSTALL from the home menu
2. Press DOWN or UP or use the rotary encoder to choose ETHERNET SETUP
menu. Press SELECT.
3. This accesses the Ethernet menu tree. Press DOWN or UP or use the rotary
encoder to choose SUBNET MASK menu. Press SELECT.
4. The screen shows:
SELECT ETHERNET SUBNET MASK
AAA BBB CCC DDD
SUBNET MASK [255] 255 255 000
<<<<< >>>>>> EDIT CANCEL SAVE
5. Use the rotary encoder to choose the address number and press >>>> or <<<<
to tab other 3-digit groups.
6. Press ENTER to leave the menu, then either SAVE (to record the changes) or
CANCEL (to leave the previous settings unchanged).
To set-up the dimmer gateway address:
1. Select INSTALL from the home menu
2. Press DOWN or UP or use the rotary encoder to choose ETHERNET SETUP
menu. Press SELECT.
3. This accesses the Ethernet menu tree. Press DOWN or UP or use the rotary
encoder to choose GATEWAY ADDRESS menu. Press SELECT.
4. The screen shows:
